ORMIG 16 tm

Approved according to law decree dated 30/04/92 n. 285 and ministerial decree dated 14/06/85 “operating machines” with free circulation.

Technical features

  • Capacity at 0.8 m from the shield: DIN 16 t – SAE 17.6 t
  • Front-wheel drive
  • Boom height: 11.5 m
  • Outreach: 7 m
  • Arm inclination: – 5° + 57°
  • Tyres: 10.00-R20
  • Single tire capacity: max. static 8000 kg
  • Maximum speed: 32 km/h
  • Diesel motor: 74.5 kW

ORMIG 55 tm

Approved according to law decree dated 30/04/92 n. 285 and ministerial decree dated 14/06/85 exceptional “operating machines”.

Technical features

  • Capacity at 1 m from the shield: DIN 50-55 t – SAE 55-60 t
  • Front-wheel drive
  • Boom height: 15 m
  • Outreach: 9 m
  • Arm inclination: – 7° + 58°
  • Tyres: 16.00-25
  • Single tire capacity: max. static 22500 kg
  • Maximum speed: 25 km/h
  • Diesel motor: 210 kW

ORMIG 75 tm

Approved according to law decree dated 30/04/92 n. 285 and ministerial decree dated 14/06/85 exceptional “operating machines”.

Caratteristiche tecniche

  • Capacity at 1 m from the shield: DIN 75 t – SAE 83 t
  • Front-wheel drive
  • Boom height: 16.5 m
  • Outreach: 10.5 m
  • Arm inclination: – 7° + 57°
  • Tyres: 18.00-25
  • Single tire capacity: max. static 30600 kg
  • Maximum speed: 25 km/h
  • Diesel motor: 240 kW

ORMIG 5.5 tmE

Approved according to law decree dated 30/04/92 n. 285 and ministerial decree dated 14/06/85 “operating machines” with free circulation.

Technical features

  • Capacity at 1 m from the shield: DIN 5.5 t – SAE 6 t
  • Front-wheel drive
  • Boom height: 9.5m
  • Outreach: 6 m
  • Arm inclination: – 9° + 62°
  • Tyres: 7.00-R15
  • Single tire capacity: max. static 3775 kg
  • Maximum speed: 6.25 km/h
  • Power supply: 80 Volt 420 Ah
  • Electric motor: 10 kW
  • Hydraulic system/services motor: 10 kW

ORMIG 15iE

The ORMIG 15iE is the most compact of its range, entirely radio-controlled crane with a capacity of 15 tonnes. The machine was conceived and designed to operate mainly indoors and in very confined spaces thanks to its very small dimensions: the width is 1.84 m and the height is 1.90 m.

In order to facilitate transport in all areas, the weight of the crane in the standard version is 13 tonnes.

Also the ORMIG 15iE, like all ORMIG models, has four points of support on the ground, in order to guarantee the best lateral stability during the translation phase with the applied load.

There are many options available including hydraulic and mechanical jibs, perfect where working heights are minimal. Furthermore, the crane can be equipped with front stabilizers (front jacks) positioned inside the frame to substantially increase the capacity.

ORMIG 16 tmE

Approved according to law decree dated 30/04/92 n. 285 and ministerial decree dated 14/06/85 “operating machines” with free circulation.

Technical features

  • Capacity at 0.8 m from the shield: DIN 16 t – SAE 17.6 t
  • Front-wheel drive
  • Boom height: 11.5 m
  • Outreach: 7 m
  • Arm inclination: – 5° + 57°
  • Tyres: 10.00-R20
  • Single tire capacity: max. static 8000 kg
  • Maximum speed: 12.19 km/h
  • Power supply: 96 Volt 900 Ah
  • Electric motor: 36 kW
  • Hydraulic system/services motor: 26 kW

ORMIG 25 tmE

Approved according to law decree dated 30/04/92 n. 285 and ministerial decree dated 14/06/85 “exceptional operating machines”.

Technical features

  • Capacity at 0.7 m from the shield: DIN 25 t – SAE 27.5 t
  • Front-wheel drive
  • Boom height: 12.7 m
  • Outreach: 7.7 m
  • Arm inclination: – 5.5° + 61°
  • Tyres: 12.00-R24
  • Single tire capacity: max. static 12420 kg
  • Maximum speed: 10.34 km/h
  • Power supply: 96 Volt 1000 Ah
  • Electric motor: 36 kW
  • Hydraulic system/services motor: 26 kW

ORMIG 35iE

The ORMIG 35iE, a crane with a maximum capacity of 35 tonnes, shares the layout of the modular counterweights with its sister, the 40iE, featuring four different configurations with increasing capacities.

Even the Ormig 35iE, like all ORMIG models, has four points of support on the ground, in order to guarantee the best lateral stability during the translation phase with the applied load.

There are many options available, including highly versatile hydraulic and mechanical jibs.

Approval according to Law Decree of 04/30/92 n. 285 and Ministerial Decree of 06/14/85 as “exceptional operating machine”.

ORMIG 40iE

The ORMIG 40iE, a crane with generous capacities reaching 40 tonnes, shares the layout of the modular counterweights with its sister, the 35iE, featuring four different configurations with increasing capacities.

The steering system is designed in the same way as all the other ORMIG iE, it has four points of support on the ground, in order to guarantee the best lateral stability during the translation phase with the load applied and larger rear wheels to distribute the pressure on the ground.

There are many options available, including highly versatile hydraulic and mechanical jibs.

Approval according to Law Decree of 04/30/92 n. 285 and Ministerial Decree of 06/14/85 as “exceptional operating machine”.

ORMIG 55/60iE

The ORMIG 55/60iE, progenitor of the iE range, has a maximum capacity of 60 tonnes and six different configurations thanks to the modular counterweights, so as to respond to needs of increasing capacity.

The four points of support on the ground are also guaranteed with pneumo-hydraulic suspensions with three settings, giving lateral stability during the translation phase with the load applied.

Also for the ORMIG 60iE there are various options available: highly versatile hydraulic and mechanical jibs, radio control, winch, etc.

Approved according to Law Decree of 04/30/92 n. 285 and Ministerial Decree of 06/14/85 as “exceptional operating machine”.
